Description
Compression fittings made from polypropylene guarantee excellent watertightness in every pressure class. Rated pressure resistance for nominal diameters 20/32/40/50/63 mm is PN16, and for nominal diameters 75/90/110 mm – PN10.
|
DN / OD a [mm]
|
DN / OD b [mm]
|
DN / OD c [mm]
|
Color
|
Pressure class [bar]
|
Pack [pcs]
|
Code
|
|---|---|---|---|---|---|---|
| 20 | 20 | 20 | blue/black | PN 16 | 30 | 4121090200 |
| 25 | 25 | 25 | blue/black | PN 16 | 20 | 4121090250 |
| 32 | 32 | 32 | blue/black | PN 16 | 12 | 4121090320 |
| 40 | 40 | 40 | blue/black | PN 16 | 6 | 4121090400 |
| 50 | 50 | 50 | blue/black | PN 16 | 8 | 4121090500 |
| 63 | 63 | 63 | blue/black | PN 16 | 10 | 4121090630 |
| 75 | 75 | 75 | blue/black | PN 10 | 6 | 4121090750 |
| 90 | 90 | 90 | blue/black | PN 10 | 4 | 4121090900 |
| 110 | 110 | 110 | blue/black | PN 10 | 1 | 4121091100 |
